Wellington Fibre Diversity
Vital Access Fibre
Leverage Vital’s own Wellington fibre network in conjunction with Chorus to architect a solution for your clients that guarantees more resiliency and, as a result, more uptime.
Who is Vital Access for?
Adding diversity and resilience to your clients’ connectivity is “vital” (excuse the pun) when they have business critical apps in play, whether on-site or hosted in the cloud, they can’t afford to be offline.
Vital Access is delivered over Vital’s own fibre network, which makes it an excellent secondary connection to ensure your clients’ uptime.
Vital Access Service Types
Vital’s Fibre services largely mirror Chorus’ Bitstream 2 (BS2) products with Vital offering an Ultra Fast Broadband (UFB) and Hyperfibre equivalent under their “Vital Access” product range.
Entry level, best effort service with standard restore time
Includes Enterprise features such as multi-VLAN capability and enhanced SLAs but without the full committed bandwidth
100% Committed Information Rate (CIR). Looking at this option? We recommend Chorus Bitstream 4 or HPA
DRIVING PROFITABILITY FOR 100+ MSPs
Vital Access Plans
To keep things simple and understandable, we’ve included the more commonly known Chorus equivalents in the plans below for comparison purposes. An advantage Vital offers symmetrical speeds and their top end Hyperfibre equivalent tops out at 10Gbps.
| Vital Product Name: | Chorus Equivalent: |
|---|---|
| Vital Access 2 – 500/500 | Chorus Bitstream 2 Small Business Fibre 500/500 |
| Vital Access 2 – 1000/1000 | Chorus Bitstream 2 Small Business Fibre Max/500 |
| Vital Access 3 – 1000/1000 | Chorus Bitstream 3 Max/Max |
| Vital Access 3 – 10000/10000 | Chorus Hyperfibre Business 8000 |
The Vital Access ONT
The Optical Termination Unit (ONT) used for Vector Eclipse which delivers integrates XGS optical WAN interface traffic speeds up to 10Gbps is the Vector Calix GH3200X GigaHub ONT.
| ONT: | Calix GH3200X GigaHub |
|---|---|
| PON WAN Tech: | 10 Gigabit XGS-PON |
| Customer handoff: | 10GE port (auto negotiating 1000/2500/10G Base-T) |
| Power input: | AC 240v supply to 12v DC input (supplied) |
| Dimensions: | H 28cm x W 9.25cm x D 17.8cm |
| Operating temperature: | Indoor ambient temperature 0°C – 40°C |
| Mounting: | Wall mount or desktop mount |
Vital Access Service Specifications
Below is a high-level overview from Vital about the Access product that’s available through Lightwire:
| Product Name: | Vector Eclipse |
|---|---|
| Service type: | Access-EPL |
| Access speed: | 1Gbps, 10Gbps |
| Bandwidth options: | 500 Mbps 1 Gbps 2 Gbps 4 Gbps 8 Gbps |
| Redundancy: | Core Redundancy |
| Diversity: | On request subject to availability |
| Service frame format (UNI): | Default (will accept tagged or untagged frames) |
| RSP handover (ENNI): | 802.1ad (SVID) 802.1q (SVID) |
| MTU size: | 9100 |
| MAC address limit: | None |
| Physical medium (UNI): | Copper |
| UNI speed: | 1000Base-T, 10GBase-T |
| L2CP support: | Forward |
| CIR CoS: | All PCP values |
| CE-VLAN ID preservation: | Preserve |
| CE-VLAN PCP preservation: | Enabled |
| Frame delivery: | Unconditional |
Request information
Want to know more or check if your client is in coverage for Vital Access?
Fill out the form below to request information about Vital Access, and a Lightwire Account Manager will reach out to you within 1 business day.
